View In:   ArcGIS Online Map Viewer

Name: Road Name Labels

Display Field: NAME

Type: Feature Layer

Geometry Type: esriGeometryPolyline

Description: SDE polyline feature class used to capture the 911 street centreline data. Used for establishing addresses as well.

Service Item Id: 0a8a78e0bd4448bf90026dbd02e3fd2c

Copyright Text:

Default Visibility: false

MaxRecordCount: 5000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 0.0

Max Scale: 0.0

Supports Advanced Queries: true

Supports Statistics: true

Can Scale Symbols: false

Supports ValidateSQL: true

Supports Calculate: true

Supports Datum Transformation: true

Extent:

XMin: 331723.19489999954
YMin: 5427712.307499999
XMax: 465933.4594999999
YMax: 5519646.1941
Spatial Reference: 26911  (26911)  LatestVCSWkid(0)

Drawing Info:

Renderer:
Simple Renderer:
Symbol:
Style: esriSLSSolid
Color: [255, 255, 255, 0]
Width: 1
Label: N/A
Description: N/A
Transparency: 0
Labeling Info:
Label Placement: esriServerLinePlacementCenterAlong
Label Expression: N/A
Use Coded Values: true
Symbol:
Color: [0, 0, 0, 255]
Background Color: N/A
Outline Color: N/A
Vertical Alignment: bottom
Horizontal Alignment: left
Right to Left: false
Angle: 0
XOffset: 0
YOffset: 0
Size: 10
Font Family: Arial
Font Style: normal
Font Weight: normal
Font Decoration: none

Min. Scale: 50000.0
Max. Scale: 0.0
Label Placement: esriServerLinePlacementCenterAlong
Label Expression: N/A
Use Coded Values: true
Symbol:
Color: [0, 0, 0, 255]
Background Color: N/A
Outline Color: N/A
Vertical Alignment: bottom
Horizontal Alignment: left
Right to Left: false
Angle: 0
XOffset: 0
YOffset: 0
Size: 12
Font Family: Arial
Font Style: normal
Font Weight: normal
Font Decoration: none

Min. Scale: 0.0
Max. Scale: 0.0
Label Placement: esriServerLinePlacementCenterAlong
Label Expression: N/A
Use Coded Values: true
Symbol:
Color: [0, 0, 0, 255]
Background Color: N/A
Outline Color: N/A
Vertical Alignment: bottom
Horizontal Alignment: left
Right to Left: false
Angle: 0
XOffset: 0
YOffset: 0
Size: 8
Font Family: Arial
Font Style: normal
Font Weight: normal
Font Decoration: none

Min. Scale: 50000.0
Max. Scale: 0.0

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: true
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false

HasZ: false

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field:

Fields:

• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID, editable: false, nullable: false, defaultValue: null, modelName: OBJECTID )
• DISPLAYNAM ( type: esriFieldTypeString, alias: DISPLAYNAM, editable: true, nullable: true, length: 40, defaultValue: null, modelName: DISPLAYNAM )
• PREFIX ( type: esriFieldTypeString, alias: PREFIX, editable: true, nullable: true, length: 2, defaultValue: null, modelName: PREFIX )
• NAME ( type: esriFieldTypeString, alias: NAME, editable: true, nullable: true, length: 30, defaultValue: null, modelName: NAME )
• TYPE ( type: esriFieldTypeString, alias: TYPE, editable: true, nullable: true, length: 5, defaultValue: null, modelName: TYPE )
• SUFFIX ( type: esriFieldTypeString, alias: SUFFIX, editable: true, nullable: true, length: 2, defaultValue: null, modelName: SUFFIX )
• COMMUNITY ( type: esriFieldTypeString, alias: COMMUNITY, editable: true, nullable: true, length: 30, defaultValue: null, modelName: COMMUNITY )
• PROV ( type: esriFieldTypeString, alias: PROV, editable: true, nullable: true, length: 2, defaultValue: null, modelName: PROV )
• FDMID ( type: esriFieldTypeDouble, alias: FDMID, editable: true, nullable: true, defaultValue: null, modelName: FDMID )
• Shape__Length ( type: esriFieldTypeDouble, alias: Shape.STLength(), editable: false, nullable: false, defaultValue: null, modelName: Shape.STLength() )
• GlobalID ( type: esriFieldTypeGlobalID, alias: GlobalID, editable: false, nullable: false, length: 38, defaultValue: null, modelName: GlobalID )

Templates:

• Name: Road Name Labels
  Description:
  Prototype:
  FDMID: null
  DISPLAYNAM: null
  PREFIX: null
  NAME: null
  TYPE: null
  SUFFIX: null
  COMMUNITY: null
  PROV: null

  Drawing Tool: esriFeatureEditToolLine

Capabilities: Query

Sync Can Return Changes: true

Is Data Versioned: true

Supports Rollback On Failure: false

Supports ApplyEdits With Global Ids: false

Edit Fields Info:

• Creation Date Field: created_date
• Creator Field: created_user
• Edit Date Field: last_edited_date
• Editor Field: last_edited_user

Supports Query With Historic Moment: false

Supports Coordinates Quantization: true

Supported Operations:   Query   Query Attachments   Query Analytic   Calculate   Validate SQL   Generate Renderer   Return Updates   Iteminfo   Thumbnail   Metadata
